Calcium Silicate Pipe
Calcium silicate pipe is high temperature,light weight and free of asbestos.Operating temperature up to 1200°F.Calsil insulation pipe is used for high temperature and equipment.
■ Color : White
■ Density :220kg/m3
■ Package: Carton
Overview of Calcium Silicate Pipe
Calcium silicate pipe is flexible,light weight and have low thermal conductivity.It have good strength and easy to install.These features of calcium silicate not only save energy also improve efficiency of insulation.
Calcium silicate pipe is composed of SiO 43%,CaO 44% and reinforcing fiber.The produce procedure is stirring,heating,gelling,forming,pipe hardening and drying.
Calcium silicate can withstand continuous temperature up to 1200°F.
Available grade
We supply calcium silicate insulation in three different forms:pipe,block and board.
Features
Flexible and easy to handle
Light weight and low thermal conductivity
Long service life
High strength and durability
Inorganic,asbestos-free and noncombustible
No loss of insulation integrity
Application
Calcium silicate pipe(block) is used for high temperature insulation,such as:
Electric equipment,metallurgical equipment
Glass furnace and all kinds of funace body
Petrochemical and power generation industries
Chemical plants,refineries and steam electric power plants
How to Order Calcium Silicate Pipe?
If you need calcium silicate pipe or need specific dimensions & shapes,please contact us to Take A Quote,we will offer more details to help.
Normal cargo will be delivered by sea transportation.
Payment Term:TT
Lead Time: Please contact us to confirm.
Data Sheet
Items | Calcium silicate pipe |
Classified Tem (℃) | 650℃/1200℉ |
Density (kg/m³) | 220 |
Bending Strength (Mpa) | ≥0.3 |
Conpressive Strength (Mpa) | ≥0.6 |
Thermal Conductivity （w/m.k） | ≤0.062 |
Linear Shrinkage （%） | ≤1.5 |
Max. working Tem. (℃) | 650 |
Size (mm) | 1000*500/600*300 |
